Description
Product Overview
This dual overlay board is a fast-track subfloor system, specially designed for installation over dB Matting when using LVT finishes. This method provides a smooth and stable surface onto which all types of resilient floor coverings can be glued directly with minimal mess.
The twin layers of MDF panels utilize an overlap joint configuration to produce a seamless surface, preventing lines from ghosting through shiny floor finishes. This is a dry process with no setting times, allowing your floor finish to be laid right away!
Technical Specifications
The dual overlay board features:
- Impact Reduction: 21 dB ΔLw
- Thickness: 7mm (Base Board 3mm / Top Board 4mm)
- Weight: 5.3 kg / m²
- Sheet Dimensions: 1.2m x 0.6m
- Area Covered: 2.88㎡
Installation Benefits
The 3 mm baseboards and 4 mm topboards are coated with a special interactive contact adhesive that ensures a strong, permanent full surface bond. Strict quality controls during production guarantee excellent results and a trouble-free installation every time.
Applications
The Premium Dual Overlay Board creates the ideal subfloor for:
- LVT
- Linoleum
- Vinyl
- Laminate
- Engineered Wood
- Rubber
- Carpet Tile
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Impact Reduction | 21 dB ΔLw |
| Thickness | 7mm (3mm Base / 4mm Top) |
| Weight | 5.3 kg/m² |
| Sheet Dimensions | 1.2m x 0.6m |
| Area | 2.88㎡ |
FAQ
-
Can this board be used with any type of flooring?
Yes, it is suitable for LVT, linoleum, vinyl, laminate, engineered wood, rubber, and carpet tile. -
How long does the installation take?
Since this is a dry process with no setting times, you can lay your floor finish immediately after installation. -
What is the impact reduction rating?
The board provides an impact reduction of 21 dB ΔLw.
