Description
What is the Acoustic Building Board?
The Acoustic Building Board is an innovative solution designed for creating ceilings and wall linings that effectively resist the passage of sound. Constructed from a high-density gypsum board and a polymeric layer, this board boasts a thickness of just 13mm, ensuring a lightweight yet robust product that delivers exceptional acoustic performance.
Engineered to meet modern construction standards, the board excels in reducing flanking transmission as part of a comprehensive wall lining system. It is ideal for installations requiring high levels of sound insulation.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Thickness | 13mm |
| Sheet Dimensions | 1.18m x 0.58m |
| Area Coverage | 0.68㎡ |
| Impact Rating | 59dB LnTw |
| Airborne Rating | 62dB DnTw +Ctr |
This building board is suitable for use with Maxi HP Screws, Resilient Bars, MF Ceiling Systems, and independent wall lining systems. When installed on an MF Metal Ceiling Grid, the system can significantly enhance the acoustic performance of existing structures.
Technical Data
- Weight: 19kg/m2
Installation Guidance
For effective installation, ensure proper alignment and secure attachment to the structure using compatible fasteners. This product is designed to integrate seamlessly with various construction methods, providing flexibility in application.
FAQ
How many sheets do I need for my room?
For a room with dimensions 4m x 3m, you will need approximately 18 sheets of the Acoustic Building Board, calculated based on the area coverage of 0.68㎡ per sheet.
Can this board be used for both ceilings and walls?
Yes, the Acoustic Building Board is suitable for use on both ceilings and walls, providing versatile applications in sound insulation.
