Description
Product Overview
Introducing a Premium High-Performance Acoustic Building Board, designed for versatile applications on both walls and ceilings. This innovative board meets the sound insulation performance requirements of Part E of the Building Regulations, making it an ideal solution for separating structures.
This product serves as an exceptional alternative to conventional plasterboard, significantly enhancing the acoustic performance of both existing and newly constructed walls and ceilings.
Manufactured from a patented composite material consisting of cement and gypsum with a polymeric core, this acoustic building board offers superior sound insulation and is highly resistant to impact. It is engineered to allow screws and fixings to be secured directly into the board, providing ease of installation.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 1200mm |
| Width | 600mm |
| Thickness | 17mm |
| Weight | 24kg/m² |
Installation Recommendations
For optimal results, it is recommended to install this acoustic board using Maxi HP Screws, SRS Gripfix, and Acoustic Sealant AC50. For instance, if your wall or ceiling dimensions are 4m x 3m (totaling 12m²), you will require approximately 17 sheets of the acoustic board, rounding up based on installation needs. Additionally, for every four boards used, one SRS Gripfix is needed for the lapped joint.
Benefits
- Exceptional sound insulation performance for quieter environments.
- High impact resistance, allowing for durability and longevity.
- Easy to install with direct fixing capabilities.
- Suitable for both new constructions and renovations.
Frequently Asked Questions
Q: What is the best way to install the acoustic board?
A: It is best to install the board on a 50mm independent lining with a 25mm air gap, and ensure the stud is filled with dB Slab 50 for enhanced performance.
Q: Can this board be used in humid environments?
A: Yes, the composite material is designed to perform well in various environments, but it is recommended to consult specific installation guidelines
